Long Range Ceramic UHF Gen 2 Wristband Tag

GAO RFID’s 116325 Ceramic material UHF Gen2 wristband type RFID tag features a water and dust resistant design and is durable and comfortable to use.

Description

Overview:

GAORFID 116325 Ceramic material UHF Gen2 wristband type RFID tag features a water and dust resistant design and is durable and comfortable in use. This tag is ideal for personnel or access control applications such as patients tracking, kids tracking or elder tracking. This wrist watch tag has a super long read range of up to 3-6 meters and provides an IP67 protection rating.

Download Our PDF Product Document

Key Features

Technical Specifications

Performance Parameters
Operating Frequency 902MHz – 928MHz, 865MHz – 868MHz (Optional)
Read Range Up to 6 meters on wrist with stationary readers; 3 meters with handheld readers
Chip Parameters
Chip R6
Functionality Read/Write
EPC 96bits
User Memory 512 User Bits
TID 64bits
Access password 32bits
Kill password 32bits
EEPROM data retention 10 years
EEPROM write endurance 100,000 cycles
Mechanical Parameters
Dimensions 265mm*32mm*18mm
Case Material TPU,PC+ABS
Color Yellow/Black
Weight 15g
Application Environment
Protection Grade IP67
Operating Temperature – 30 °C – + 90 °C
