Description
Overview
GAO RFID’s 2.45 GHz Active RFID Card Tag is used to identify and perform micro-localization of items or persons. It provides up to 100 m of read range yet uses very little power. Life expectancy is approximately 4 years. The tags unique anti-collision feature allows for a simultaneous read of up to 100 tags. A slot in the card allows for the attachment of a lanyard or tie. It is typically used for manufacturing and security applications or asset management. The tag is built around an innovative 0.18 μm low-power CMOS integrated circuit.
Key Features
- Unique anti-collision feature.
- Can identify 100 tags simultaneously at distance up to 100 m.
- Innovative 0.18 μm CMOS IC technology for ultra-low power consumption.
Applications
- Security
- Asset Management
- Manufacturing
- Vehicle Management
Technical Specifications
| Range | 0 ft – 328 ft (0 m to 100 m) |
| Frequency | 2.4 GHz to 2.5 GHz ISM |
| Weight | 0.11 lbs (50 g) |
| Modulation | GFSK |
| Power | 12 µA to 18 µA, 3 V |
| Anti-collision | 100 tags are read simultaneously |
| Operation | Read only |
| Battery | 4 years |
| Dimensions | 3.37 in × 2.12 in × 0.15 in (85.5 mm x 54 mm x 4 mm) |
