Description
Overview
GAOTek 2GE+2.4GWiFi+5GWiFi GPON/EPON HGU terminal devices are designed for fulfilling FTTH and triple play service demand of fixed network operators. These boxes are based on the mature Chipset (Realtek) technology, which has high ratio of performance to price, and the technology of IEEE802.11b/g/n/ac WiFi, Layer 2/3. Support full management of HGU devices through OLT. They are highly reliable and easy to maintain, with guaranteed QoS for different services. And they are fully compliant with technical regulations such as IEEE802.3ah> ITU-T G.984.x and technical requirement of GPON Equipment (V2.0 and above version) from China Telecom.
Features
- Support full management of HGU functions
- Plug and play, features auto-detecting, auto-configuration, and auto firmware upgrade
- Integrated OAM/OMCI remote configuration and maintenance function
- Support rich QinQ VLAN functions and IGMP Snooping multicast features
- Fully compatibility with OLT based on Broadcom/PMC/Cortina chipset
- Support TR069 one-key batch configuration
- Support 802. 11 a/b/g/n/ac WiFi(2 x 2T2R) function
- Support NAT, Firewall function
- Support IPv4 and IPv6 dual stack.
Technical Specifications
| Technical item | 2 GE+ 2 4 GWiFi+ 5 GWiFi |
| PON interface | 1 G/ EPON port (EPON PX2 0 + and GPON Class B+) Receiving
Sensitivity < to 2 8dBm Transmitting optical power 0 to + 4 dBm Transmission distance: 2 0KM |
| Wavelength | Tx 1310nm, Rx 1490nm |
| Optical interface | SC or APC connector |
| LAN interface | 2 x 10 or 100 or 1000Mbps auto adaptive Ethernet interfaces,
Full or Half, RJ4 5 connector |
| WiFi interface | Compliant with IEEE802. 1 1 a or b or g or n or ac
2.4GHz Operating frequency 2.400 to 2.483GHz 5.0GHz Operating frequency 5. 150-5.825GHz Support MIMO, 2 x 2T2R, 5 dBi external antenna, rate up to 1. 1 67Gbps Support multiple SSID TX power 11n 22dBm or 1 1ac 24dBm |
| LED | POWER, PON, LOS, LAN2, LAN1 ,2.4G ,5G, FXS, RF |
| Power supply | DC 12V or 1.5A |
| Power supply | <9W |
| Net weight | 11.29 oz (0.32Kg) |
| Operating condition | Temperature 32 °F to 122 °F (0 °C to + 50 °C)
Humidity 1 0% to 9 0% (non- condensing) |
| Storing condition | Temperature -22 °F to 140 °F (-30 °C to + 60 °C)
Humidity: 1 0% to 9 0% (non- condensing) |
| Dimension | 9.57 in x 5.94 in x 1.18 in (243 mm x 151 mm x 30 mm) |
