Description
Overview
4G LTE Outdoor IoT Router for BLE Beacon with Waterproof Design – GAOTek is mainly used for communicating with devices with BLE function, and uploading device data to the cloud, or download cloud data to device. KG01 gateway support cellular (3 G or 4 G), Wi-Fi, Wi-Fi hopping, or ethernet network connection. It can be powered by DC 5 V, or POE (802.3af). It supports Bluetooth 5.0 or 4.2or 4.1 or 4.0 and newer, e.g. BLE sensor, smart wristband, smart heart rate band.
Technical Specifications
| Material | Industry use plastic |
| Scanning Ability | > 260 beacons per second |
| Indicator | RGB LED indicator |
| Wireless Distance | BLE 4.0 or BLE 4.1 or BLE 4.2 or BLE 5.0 up to 0.093 mi (150 m) The working distance will be affected by surrounding environment) |
| Transmitting Way | Cellular (USB dongle for 3G/4G), ETH RJ45, Wi-Fi, Wi-Fi hopping |
| Transmitting Protocol | HTTPS MQTT |
| Waterproof | IP53 with smart outdoor design |
| BLE Chipset | Nordic nRF52 series |
| Power Supply | DC 5 V or POE |
| Weight | 5.29 oz (150 g) |
| Size | 6.81 in x 3.54 in x 1.77 in (173 mm x 90 mm x 45 mm) |
| Working Temperature | -40 °F to 158 °F (-40 °C to +70 °C) |
| Storage Temperature | 50 °F to 77 °F (10 °C to +25 °C), ≤ 65 % RH |
