UHF 900 MHz Linear RFID Antenna

This 900 MHz antenna is designed to operate with any application that requires a linear polarization for transponder reading/excitation.

316001

Description

Overview

Download Our PDF Product Document
Download Our PDF Product Document

This 900 MHz antenna is designed to operate with any application that requires a linear polarization for transponder reading/excitation.

Specifications

  • Polarize style: Linear polarization
  • Operating frequency: 902 to 928 MHz
  • Center frequency: 915 MHz
  • Gain: 7.15 dBi
  • VSWR: 1.3 (902 to 928 MHz)
  • Half-power wave beam width: 70°(H) , 70°(V)
  • Natural impedance: 50 Ω
  • Dimensions: 220 × 220 × 44 mm (8.66 × 8.66 × 1.73 inch)
  • Weight: <1 kg (2.20 lb)
  • Case material: Glass fiber reinforced plastic
  • Protection: Waterproof, acid-proof

Operating Specifications

  • Operating Temperature: -0 °C to 60 °C
  • Storage Temperature: -20 °C to 70 °C
  • Humidity: 10 to 90% relative

Compatibility

  • Antenna Compatibility: Any 902 to 928 MHz. Reader
  • Antenna Connection: SMA Female
  • Transponder Compatibility: Any 902 to 928 MHz. transponder
