Description
Overview
This compact long-range UHF RFID reader-writer is designed for high-speed and reliable asset tracking, inventory management, and event timing. With a powerful 33 dBm output, Wi-Fi connectivity, and support for reading up to 400 tags per second, it ensures efficiency in diverse applications. Its lightweight design makes it easy to integrate into fixed or portable setups. Compliant with ISO 18000-6C protocols, it offers robust performance for modern RFID needs.
Features
- Powerful Output: Adjustable RF power from 5 dBm to 25 dBm
- Multi-Tag Support: Reads up to 400 tags per second for high efficiency
- Connectivity Options: Supports Wi-Fi, GPIO, and USB for seamless integration
- Long Range: Reads tags up to 32.81 ft (10 m) for wide coverage
- Protocol Compatibility: ISO 18000-6C compliant for universal tag support
- Low Power Consumption: Operates on USB power supply at 15 dBm
Applications
- Asset tracking in warehouses and distribution centres
- Inventory management in retail and logistics
- Race timing for marathons and sporting events
- Library book tracking and management
- Access control in secure facilities
Technical Specifications
| Frequency | 860 MHz to 960 MHz |
| Protocol | ISO 18000-6C |
| Operating Voltage | USB Power supply @ 15 dBm |
| Maximum Current | 380 mA |
| Multi-Tag Read Rate | 400 tag per s |
| RF Power Output | 5 dBm to 25 dBm |
| Size | 5.07 in x 3.14 in x 0.866 in (12.9 cm x 8 cm x 2.2 cm) |
| Maximum Reading Range | 32.81 ft (10 m) |
| Weight | 6.3492 oz (180 g) |
