Description
Overview
GAOTek base station supports UWB indoor positioning technology, data transmission Bluetooth WiFi 4GPOE supports three-dimensional, two-dimensional, one-dimensional and zero-posit ion positioning, supports TDOA and TOF technologies, the communication distance of the base station is 500 M-1000 M, and the positioning accuracy is 10CM, Lightning protection, waterproof and explosion protection.
Technical Specifications
| Working frequency | Working frequency |
| Positioning type | TFO/TDOA |
| Transmit power | -41.3 dbm/MHz |
| Power supply mode | POE or DC power supply |
| Positioning accuracy | 10 cm (no obstruction) |
| Protection grade | IP67 |
| Size | 9.3 in x 6.02 in x 3.07 (237 mm x 153 mm x 78 mm) |
| Working temperature | −22 ºF to 176 ºF (-30 ℃ to +80 ℃) |
| Storage temperature | −40 ºF to 194 ºF (-40 ℃ to +90 ℃) |
| Working humidity or storage humidity | 0 % to 95 % (no condensation) |
| Weight | 2.64 lb (1200 G) |
