Description
Features
- Android 9.0 rugged tablet with abundant functions
- Qualcomm 1.8 GHz Octa-core
- An extra layer of protection is provided by Corning Gorilla Glass which makes it damage and scratch resistant
- RAM + ROM: 2+16 GB / 3+32 GB
- It adopts Zebra scan engine which enables lightening-fast capture of 1D/2d barcodes including dirty and poorly printed codes
- Deploys with latest IPS Technology in its 8-inch screen with full HD 1920 × 1200/ 1280 × 800 IPS Display
- 8000 mAh Powerful and rechargeable Large Battery
- It can read all kinds of RFID tags with high accuracy and speed
- Features with Ultrafast 4G / Dual-band Wi-Fi (2.4G + 5G) and low consumption bluetooth
- IP65 per IEC sealing specifications making it water and dust proof
- Support up to 128 GB Micro SD card
- It supports ISO/IEC 18092 and ISO/IEC 21481 protocols for Near-Field Communication (NFC)
- 13 MP Autofocus camera with well-functioning flash function, 8 MP front camera
- 5 to 7 charging hours with standard AC adaptor and USB cable
- Accurate Barcode Scanning provides wide scanning rage and scan distance which is convenient with 1D/2D barcodes
- Enhanced PSAM Security level (optional) supports protocol of ISO7816
- Built with fingerprint function ensures its security and fake finger detection
- Iris Recognition is installed with the range between 7.8 to 15.7 in (20-40 cm) and the rate less than 150 ms
- UHF RFID, R/W ranges greater than 82.02 ft. (25 m) (indoors), greater than 49.21 ft. (15 m) (open outdoors, Impinj MR6 tag), reading rates greater than 200 tags/s
Applications
- Used in various Industrial fulfillments, such as retail, logistics, power, warehousing, transportation and so forth
Technical Specifications
| Physical Characteristics | |
| Display | 8_inch IPS LTPS 1920 × 1200 / IPS LTPS 1280 × 800 |
| Touch Panel | Corning Gorilla Glass, multi-touch panel, gloves and wet hands supported |
| Humidity | 5% RH – 95% RH non condensing |
| Weight | 1.54 lbs. (700 g) |
| Keypad | 1 front key, 1 volume key, 1 power key, direction key (optional) |
| Interfaces | USB 3.0 Type-C, OTG |
| Audio | Speaker, microphone |
| Power | Main battery: Li-ion, rechargeable, 8000 mAh Standby: over 500 hours Continuous use: over 10 hours (depending on user environment ) Charging time: 5-7 hours (with standard AC adaptor and USB cable ) |
| Dimensions | 9.87 × 5.98 × 0.59 in (250.8 × 152.0 × 15.0 mm) |
| Operating Temp. | -4 °F to 122 °F (-20 °C to 50 °C) |
| Storage Temp. | -40 °F to 158 °F (-40 °C to 70 °C) |
| Drop Specification | Multiple 4.9 ft. (1.5 m) drops (at least 20 times) to the concrete across the operating temperature range |
| Tumble Specification | 500 × 1.64 ft. (0.5 m) falls at room temperature |
| Sealing | IP65 per IEC sealing specifications |
| ESD | ±15 kV air discharge, ±8 kV conductive discharge |
| HF RFID Frequency | 13.56 MHz |
| Sensors | Gravity sensor, gyroscope, accelerometer sensor |
| Developing Environment | |
| Operating System | Android 9.0; GMS, Android Enterprise, Zero-Touch,FOTA, Soti MobiControl, SafeUEM supported |
| SDK | GAORFID Software Development Kit |
| Language | Java |
| Tool | Eclipse / Android Studio |
| Performance | |
| CPU | Qualcomm 1.8 GHz Octa-core |
| Expansion | Supports up to 128 GB Micro SD card |
| RAM+ROM | 2 GB + 16 GB / 3 GB + 32 GB |
| Camera | |
| Camera | 13 MP Autofocus with flash |
| Front Camera | 8 MP |
| PSAM | |
| Protocol | ISO7816 |
| Slots | 2 PSAM card slots |
| Finger Print | |
| Sensing Area | 0.50 × 0.71 in (12.8 × 18 mm); 0.41 × 0.57 in (10.4 × 14.4 mm); 0.55 × 0.87 in (14 × 22 mm) |
| Certifications | FIPS 201, STQC; FIPS PIV IQS / ISO 19794-4, MINEX & FIPS 201 complaint, STQC |
| Security | AES, DES key encryption of the host communication channel; FIPS 140-2 level 2, multiple security methods available, including image and templates encryption, template signature, secure tunneling, etc. |
| Format Extraction | ISO 19794, WSQ, ANSI 378, JPEG2000; ISO 19794-2/4, WSQ, ANSI 378, etc. |
| Resolution | 508 dpi, 8-bit greylevel; 500 dpi, 256 greylevel |
| Fake Finger Detection | Support by SDK; Latex, Gelatin, Plasticine, Kapton, Transparent Film, Silicone, Rubber, Play-doh, Graphite Or Paper |
| Sensor | TCS1/TCS2 Capacitive; Optical Morpho CBM-E3 |
| UHF RFID | |
| Engine | CM2000-1 module based on Impinj Indy R2000 |
| R/W ranges | ＞82.02 ft. (25 m) (indoors); ＞49.21 ft. (15 m) (open outdoors, Impinj MR6 tag) |
| Protocol | EPC C1 GEN2 / ISO18000-6C |
| Reading rates | ＞200 tags/s |
| Power | 1W (30 dBm, +5 dBm to +30 dBm adjustable) 2W Optional (33dBm, for Latin America, etc.) |
| Antenna | Circular polarization (default UHF, 3dBi ; UHF with pistol grip, 4dBi) |
| Frequency | 865-868 MHz / 920-925 MHz / 902-928 MHz |
| Barcode Scanning | |
| Scan engine | Zebra SE4710 (standard) , Zebra SE4850 (optional) |
| 1D Symbologies | UPC/EAN, Code128, Code39, Code93, Code11, Codabar, Interleaved 2 of 5, Discrete 2 of 5, Chinese 2 of 5, MSI, RSS, etc. |
| 2D Symbologies | PDF417, MicroPDF417, Composite, RSS, TLC- 39, Datamatrix, QR code, Micro QR code, Aztec, MaxiCode; Postal Codes: US PostNet, US Planet, UK Postal, Australian Postal, Japan Postal, Dutch Postal (KIX), etc. |
| Iris Recognition | |
| Protocol | ISO/IEC 19794-6，GB/T 20979-2007 |
| FAR | 1/10000000 |
| Range | 7.8-15.7 in (20-40 cm) |
| Rate | < 150 ms |
| NFC | |
| Range | 0.79-1.57 in (2-4 cm) |
| Chips | M1 card (S50, S70), CPU card, NFC tags, etc. |
| Protocol | ISO14443A/B, ISO15693, NFC-IP1, NFC-IP2, etc. |
| Frequency | 13.56 MHz |
| InfraRed | |
| Protocol | DLT_645-2007, DLT_645-1997 |
| Range | > 13.12 ft. (4 m) |
| Frequency | 38 kHz |
| Wavelength | 940 nm |
| Communication | |
| WLAN | IEEE802.11 a/b/g/n/ac, 2.4G/5G dual-band, internal antenna |
| WWAN (Europe, Asia) | 2G: B3/B5/B8
3G: CDMA EVDO: BC0 TD-SCDMA: B34/B39 WCDMA: B1/B5/B8 4G: TDD-LTE: B38/B39/B40/B41 FDD-LTE: B1/B3/B5/B7/B8/B20 |
| WWAN (America) | 3G: B2/B4/B5
4G: B2/B4/B5/B7/B12/B13/B17/B28b |
| WWAN (Others) | Depending on the country’s ISP |
| Bluetooth | Bluetooth 4.2/4.1+HS/4.0/3.0+HS/2.1+EDR |
| GNSS | GPS/AGPS, GLONASS, BeiDou, internal antenna |
Accessaries
| S. No. | Items | Images |
| 1. | Adapter (UK) | |
| 2. | Adapter (EU) | |
| 3. | Adapter (CN) | |
| 4. | Adapter (US) | |
| 5. | USB Cable | |
| 6. | Wristband | |
| 7. | Pistol (Optional) | |
| 8. | Sim Tray Ejector | |
| 9. | Rugged Rubber Boot (Optional) |
