Description
Overview
GAORFID SKU#246044 IP67 rated (MIL-STD-810G standard) Handheld Enterprise Digital Assistant, Computer or Data Terminal with 1D/2D Barcode Scanner, 4G, WIFI, Bluetooth, GPS, NFC, UHF Gen 2 RFID, Cortex-A53 Processor, Android, and Autofocus Camera is an Android-based mobile computer which features powerful 8x core processor, stable wireless connectivity (4G LTE, Wi-Fi, Bluetooth), high-resolution camera, accurate GPS, NFC and optional 1D/2D barcode scanning functions. The Handheld Computer also features quick responses to collect data, run multiple application software, and dedicated SC card slot that can accommodate SD cards up to 512 GB memory. It delivers balanced performance with efficient task management and high-speed processing power. This rugged device can be deployed in industries like express delivery, logistics, warehousing, manufacturing and so forth.
Technical Specifications
| Basic Configuration | CPU | MTK MT6765 Cortex-A53, 8 cores, 2.3GHz |
| OS | Android 12.0, support GMS | |
| Memory | RAM: 4GB, ROM: 64GB Option with 6GB+128GB |
|
| Extended Memory | Micro SD(TF) 512G at most | |
| Display | 8inch IPS Screen, 800*1280 | |
| Touch Screen | 5-point capacitive touch screen | |
| Keyboard | 5 keys physical keyboard (including function keys, power button) | |
| Wi-Fi | IEEE 802.11a/b/g/n/ac,
2.4GHz + 5GHz Dual-Frequency |
|
| Bluetooth | Bluetooth V5.0 | |
| GPS | Support GPS/Glonass | |
| NFC | NXP557, Support ISO/IEC 14443A, ISO/IEC 15693, Mifare, NFC | |
| Mobile Communications | Support 4G-LTE | 3G | GSM | CDMA
GSM: B5/850;B8/900;B3/1800;B2/1900 WCDMA: B1/2100;B2/1900;B5/850;B8/900; CDMA2000/EVDO 3G:TD/SCDMA TDD-LTE: B34/B38/B39/B40/B41 |
|
| Camera | 5MP front camera, 13MP rear camera | |
| Battery capacity | 8000mAh rechargeable polymer lithium battery | |
| Indicator | Power Indicator*1 | |
| G-Sensor | Support | |
| Light Sensor | Support | |
| Vibrating alert | Support | |
| Volume | Loud speaker volume up to 90dB, easy to deal with noisy environment | |
| Expansion slot | Micro dual sim card | |
| Interfaces | Type-C USB 2.0*1, DC*1 | |
| Mechanical Spec | Dimension | 254mm(length)*150mm(width)*24mm(thickness) |
| Net Weight | 900g (including battery) | |
| Gross Weight | 2Kg | |
| Protection Grade | IP67, MIL-STD-810G Standard, 6 sides could undertake the impact by falling from 1.22m to the cement ground for may times within the scope of operating temperature | |
| Standard Parts | Charger *1, USB Cable *1 | |
| Optional features | UHF RFID | Regulatory:
FCC (NA, SA) 917.4 – 927.2 MHz ETSI (EU) 865.6 – 867.6 MHz TRAI (India) 865 – 867 MHz KCC (Korea) 917– 923.5 MHz MIC (Japan) 916.8 – 923.4 MHz ACMA (Australia) 920 – 926 MHz SRRC-MII (P.R.China) 920.1– 924.9 MHz ‘Open’ (Customizable channel plan; 859 – 873 MHz and 915 – 930 MHz) RFID Protocol: EPC global Gen 2 (ISO 18000-6C) Read distance: 0~15m (Tags dependent) Performance: Up to 200 tags/sec reading 96-bit EPC Output range: Separate read and write levels, command adjustable: from 0 dBm to +27 dBm, in 1 dB step |
| NFC | 13.56MHz NXP557, Support ISO/IEC 14443A, ISO/IEC 15693，Mifare | |
| 2D Barcode Reader | Professional 2D Barcode Scan Engine recognize. Both 1D and 2D barcodes
1D Barcodes Supported: Code 39, Codabar, Code 128, Discrete 2 of 5, Interleaved 2 of 5, Code 93, UPC-A, UPC-E, EAN-8, EAN-13, MSI, EAN-128, ISBN/ISSN, etc. 2D Barcodes Supported:PDF417, Micro PDF417, QR Code, Micro QR, MaxiCode, Data Matrix, GS1 Composite, Australian Post, British Post, Canadian Post, Japanese Post, etc. |
|
| Fingerprint Reader | EM03-3011A Fingerprint reader or A400-M Fingerprint reader with FBI/STQC certificate | |
| Charging Dock | Charging Dock | |
