Description
Overview
Its edge and fog computing capabilities with Python programming, rich serial interface and free embedded NS, available in CN 470, IN 865, EU 868, RU 864, US 915, AU 915, KR 920 and AS 923 global frequencies.
Technical Specifications
| Processor | Quad core 1.5 GHz, 64 bit ARM Cortex A 53 |
| Memory | 512 MB DDR 4 RAM |
| Ingress Protection | IP 67 |
| Frequency Band | CN 470, IN 865, EU 868, RU 864, US 915, AU 915, KR 920, AS 923 |
| Wi-Fi | IEEE 802.11, a, b, g, n |
| Ethernet | 1 Mbps x 10 Mbps to 100 Mbps x 1000 Mbps |
| Nodes Connection | Up to 2000 |
| Radio Range | Up to 10 km (6.21 mi) |
| Flash | 8 GB EMMC |
| Network Protocol | PPPOE, SNMP, TCP, UDP, DHCP, DDNS, HTTP, HTTPS, DNS, ARP, SNTP, Telnet, SSH, MQTT |
| VPN Tunnel | Open VPN, IPsec, PPTP, L2TP, GRE, DMVPN |
| Cellular | 1 x SIM Slot |
| Sensitivity | -140 dBm Sensitivity, 292 bps |
| Output Power | 27 dBm Max |
| Operating Temperature | -40 ℉ to +158 ℉ (-40 °C to +70 °C) |
| Storage Temperature | -40 ℉ to +185 ℉ (-40 °C to +85 °C) |
| Relative Humidity | 0 % to 95 % (noncondensing) at 77 ℉ (25 °C) |
| Dimensions | 7.09 in x 4.33 in x 2.23 in (180 mm x 110 mm x 56.5 mm) |
