GAORFID’s USB-powered 13.56 MHz HF RFID Reader/Writer offers dual-mode support for HF and LF frequencies. Compact and portable, it’s ideal for applications like access control, personnel ID, POS, and logistics, with plug-and-play functionality and easy setup.

Description

Overview

The GAORFID USB-powered 13.56 MHz HF RFID Reader/Writer is a compact and versatile solution for applications such as access control, personnel ID, and logistics. With dual-mode support for HF and LF frequencies, it ensures seamless integration and easy, plug-and-play operation, making it ideal for retail, supply chain, and POS systems. Its portable design provides convenience for a range of RFID-based tasks, offering quick setup and reliable performance for various industries.



Features

  • Compact and portable design
  • Dual-mode support for HF (13.56 MHz) and LF (125 kHz) frequencies
  • Plug-and-play functionality for easy setup
  • NFC compatibility for enhanced communication
  • Lightweight and easy to carry
  • Suitable for various RFID applications like access control and logistics
  • Includes demo software and sample tags for quick installation



Applications

  • Personnel identification and verification
  • Access control for computers and terminals
  • Point-of-sale (POS) system integration
  • Supply chain tracking and management
  • Retail inventory and asset management
  • Logistics and shipment tracking



Technical Specifications

Dimensions 3.15 in x 2.24 in x 0.75 in (80 mm x 57 mm x 19 mm)
Weight 1.52 oz (approx. 43 g, without USB cable)
Housing Polycarbonate
Protecting class IP30
Operation temperature 41 ℉ to 131 ℉ (5 ℃ to 55 ℃)
Storing temperature -4 ℉ to 158 ℉ (-20 ℃ to 70 ℃)
Relative humidity 5% to 95% non-condensing
Power supply powered by USB
Current consumption Max. 150mA (operation)
Operating frequency 13.56 MHz, 125 kHz
Radiated transmit power ≤200mW
Read or write distance up to 2.76 in(70mm); dependent on type/size of tag
Transponder protocols HF (High Frequency): ISO 15693, 1-Code™, 1-Code SLI, my-D, my-D secure, ISO 14443A, MIFARE®, ISO 14443B unique identifiers

LF (Low Frequency): HITAG2, EM4002/4102, Temic chip technologies

Interface USB
Conformities Human exposure EN50364
EMC EN301 489
Air interface (EU) EN300 330
Air interface (US) FCC Port 15
