Description
Overview
GAORFID UHF reader integrated for parking access control is a compact reader with an integrated 8 dBi circular polarized UHF far-field antenna. Based on an efficient and patented digital signal processing algorithm, the reader can reach a reading range of up to 16.69 ft (6 m) and a writing range of 9.84 ft (3 m).
Technical Specifications
| Operating Frequency | 902 MHz to 928 MHz |
| Protocol | ISO18000‐6C(EPCGEN2) |
| ISO18000‐6B | |
| Frequency Hopping Mode | Fixed Frequency Band and FHSS Software Programmable |
| Antenna | 8 dBi circular polarized antenna (Integrated) |
| Output Power | 0 dBm to 18 dBm (Adjustable) |
| Read or Write Range | Max Read Range: 19.6 ft (6 m), Max Write Range: 9.84 ft (3 m)
Distance depends on Reader & Antenna Output Power |
| Operating Mode | Master‐Slave Mode (Online Mode) |
| Time Scheduled Modes | |
| Trigger Mode | |
| Power | 12 V |
| Communication Port | RS‐232 |
| Wiegand Interface: Wiegand 26 & Wiegand 34 Supported | |
| RS‐485 | |
| 10 M or 100 M Ethernet, GPRS, WIFI (for Customized Model only) | |
| Trigger | 1 x Trigger Level Input |
| General Purpose | 2 x GPIO |
| Power Supply | AC110 V to 220 V or DC 12 V |
| Cables | Power Cable |
| RS232 Serial Cable | |
| Brackets | Pole Mount Adapter |
| Software Pack (Optional) | API Software Development Kits complete with VB, C# Sample Program |
| Operation | -4 ºF to 140 ºF (-20 ºC to 60 ºC) |
| Storage | -49 ºF to 185 ºF (-45 ºC to 85 ºC) |
| Dimension | 8.94 in × 8.94 in × 2.36 in (22.7 cm × 22.7 cm × 6 cm) |
| Weight | 3.96 lb (1.8 kg) |
