Description
Features
- Small, portable and integrated reader and writer, suitable for indoor desk operation
- Compatible with ISO 18000-6C and ISO 18000-6B standards
- Fast data read rate
- High reader range and writing range – up to 1.64 ft. (0.5m) and 0.66 ft. (0.2m) respectively
- Multiple tag detection
- Multi-protocol compatibility
- Working frequency of 860MHz to 960MHz
- Built in with 2dBi circularly polarized antenna
- Output power within range of 12.5dBm to 26dBm, adjustable by software
- Available in Plug&Play USB HID mode (Keyboard Emulation) or USB to virtual serial port mode
Application
- Logistics and Warehouse management
- Manufacturing management
- Products anti-counterfeiting detection
- Parking control system
- Other field: club management, library, student school rolls, attendance management etc.
Technical Specifications
| Interface | |
| Voltage | DC +5V |
| Physical parameter | |
| Net/gross Weight | 0.33 lbs. / 0.55 lbs. (150g / 250g) |
| Size | 4.21 in x 4.21 in x 0.91 in (107mm x 107mm x 23mm) |
| Parameters | |
| Operation Mode | Fixed Frequency or FHSS or Software Programmable |
| Protocol | ISO18000-6C (EPC GEN2) |
| ISO18000-6B | |
| Working frequency | 860 – 960 MHz |
| Reader&write range | Reading Range (Maximum) : 1.64 ft. (0.5m) (related to the card or the environment) |
| Writing Range (Maximum) : 0.66 ft. (0.2m) (related to the card or the environment) | |
| Output power | 12.5dBm – 26dBm (Adjustable by software) |
| Working mode (Adjustable through software)
|
Plug&Play Keyboard Emulation |
| USB to Virtual Com Port | |
| Antenna parameter | 2dBi circularly polarized antenna (built-in) |
| Working environment | |
| Storage Temp | -40 °F – 185 °F (-40 °C – 85 °C) |
| Working Temp | -4 °F – 131 °F ( -20 °C – 55 °C) |
