BLE 2.45GHz Ultra Small Tag/Beacon



GAORFID SKU#127053 Mini Asset Beacon/tag combines together with standard iBeacon and Eddystone (UID, URL, TLM). SKU#127053 tags broadcast 2.4 to 2.5 GHz radio signals at regular and software adjustable intervals. It is being widely used in asset management, warehouse, etc.

Download Our PDF Product Document

Main Features:

  • Lightweight, small form factor design
  • Standard iBeacon, free band of 2.45GHz
  • Bluetooth® 5.0 chipset
  • The max. 100 meters reading distance with SKU#217030 gate way or any other Bluetooth Featured devices (e.g. iPhones, Android smart devices, etc.)
  • Double adhesive design, easy for mounting
  • Battery Replace-able



  • BLE sensor reader / receiver
  • Asset tracking
  • Access control management
  • Advertisement promotion
  • Indoor location and position
  • People Tracking
  • IoT related
  • Active RFID


Technical Specifications:


Size/Weight 37.6*24*5.3mm / 7g
Bluetooth Bluetooth low energy 5.0
Frequency 2.45GHz
Support Protocols Apple iBeacon, Eddystone URL, Eddystone UID, Eddystone TLM
Beaconing Interval Default 1000mS
Transmit power 0dBm
Operating / Storage temperature -40°C to 70°C / 10°C to 25°C
Humidity Max 95%, Non condensing, relative humidity
Waterproof IP44
Battery Up to 16 months and replace-able with regular CR2032 Button size battery
Motion / Vibration sensor Optional
