Description
Overview
The GAORFID Temperature Sensor Bluetooth Beacon represents a new generation of sensor technology based on iBeacon. It collects temperature and humidity data with exceptional precision and broadcasts the data to compatible devices such as smartphones or gateways. Designed with Bluetooth 5.0, this beacon ensures reliable performance, long-range connectivity, and power-efficient operation, making it ideal for various monitoring and data collection applications.
Features
- Bluetooth 5.0 BLE
- Embedded antenna for 164 ft (50 m) range in open air
- Automatic power saving mode
- Precise signal strength display
- Includes temperature and humidity testing
- Configurable sampling frequency
Applications
- Environmental Monitoring
- Healthcare
- Smart Homes and IoT
Technical Specifications
| Bluetooth Specification | BLE 5.0 |
| Spread Spectrum Method | FHSS |
| Voltage | 2.7 V to 3.3 V |
| Working Frequency | ISM frequency 2.400 GHz to 2.483 GHz |
| Transmitting Power | 0 dBm |
| Transmitting Distance | 98.4 ft (30 m) |
| Receiving Sensitivity | <96 dBm at <0.1 % BER |
| Connecting Standby Power | 0.2 mA |
| Antenna Standard | 2.4 G, 50 ohms |
| Safety Standard | AES 128 bit |
| Relative Humidity | 0 % RH to 100 % RH |
| Temperature Measure Accuracy | 59 °F to 104 °F (15 °C to 40 °C) deviation is ± 0.5 -40 °F to 185 °F (-40 °C to 85 °C) deviation is ± 1 |
| Temperature Measure Range | -40 °F to 185 °F (-40 °C to 85 °C) |
| Store Temperature | -67 °F to 257 °F (-55 °C to 125 °C) |
