Description
Overall:
The Gen2 UHF On/Off Metal RFID tag is specially designed for metallic asset tracking under outdoor or extremely harsh environments. Attached on metal with long reading distance, mainly used for asset management heavy industry, metallic asset tracking, oil & gas & mining, automatic production line, warehouse shelf, container tracking, etc.
Features:
- Compliant with ISO18000-6C (EPC C1G2) standard
- Applicable for all types of surfaces like metal, plastic, and liquids
- IP66 Rated
- Waterproof and anti-collision
Applications:
- Asset tracking
- Logistics and automotive
- Manufacturing and work-monitoring
Technical Specifications:
| RF Specifications | |
| RF Air Protocols | EPC Class1 Gen2; ISO18000-6C |
| Operating Frequency | 902-928 MHz |
| Read Distance | Up to 16 Meters (Reader/Antenna Dependent) |
| IC Type | Impinj M750 |
| Memory Configuration | EPC 96 bits, User 512-bits, TID 96-bits |
| IP Classification | IP66 |
| Mechanical Specifications | |
| Material | Engineering Plastic |
| Dimensions | 88 X 22 X 12mm |
| Weight | 25g |
| Installation | 3M adhesive, Screw, Cable |
| Environmental Specifications | |
| Operating Temperature | -15°C to 65 °C |
