Description
Product Overview
GAORFID robust UHF RFID tag is designed to endure extreme environments with IP68/IP69K ratings and resistance to high pressure, vibrations, and chemicals. Its unique RF design ensures reliable performance with read ranges of up to 4.92 ft. Made from durable stainless steel 304, it offers quick snap-in attachment and embedded mounting. Withstanding temperatures up to 250°C, it is ideal for industrial and hazardous applications. Compliant with RoHS, CE, and ATEX/IECEx standards, it ensures reliability in diverse settings.
Features
- Withstands high pressure and vibrations
- Quick snap in attachment
- Unique RF design
- IP68, IP69K
- Hi-Temp and chemicals resistance
Applications
- Equipment tracking in high-pressure environments
- Industrial machinery monitoring and asset management
- Oil and gas industry tool identification
- Aerospace and automotive components tracking
- Healthcare sterilization and chemical processing monitoring
Technical Specifications
| Performance Characteristics | |
| Read Range (handheld) | Up to 3.8 ft (1.0 m) |
| Read Range (fixed) | Up to 4.92 ft (1.5 m) |
| Polarization | Linear |
| Mounting System | Snap in, embedded |
| Functional Specifications | |
| RF Protocol | EPC global Class 1 Gen2 |
| Frequency | 902-928 (US) ; 865-868 (EU) |
| IC type (chip) | Alien Higgs-3 |
| Memory | 96-EPC bits,
64-bit unique TID, 512 -bit user memory |
| Material | Stainless steel 304 |
| Environmental Specifications | |
| Operational Temperature | -40°C to +85°C |
| Survival Temperature | -40°C to +250°C |
| Chemical Resistance | Withstands drilling fluids and hydraulic fluids
including hydrogen sulphide. |
| IP rating | IP68, IP69K |
| Compression Strength | 30,000 psi (206 MPa) |
| Shock (drop) | 3 ft (1 m) to concrete/granite |
| Vibration | MIL-STD-810G |
| Product Dimensions and Weight | |
| Dimensions (in) | ø 1.11 x 0.33 |
| Tolerance | +/- 0.004 |
| Dimensions (mm) | ø 28.3 x 8.5 |
| Tolerance | +/- 0.1 |
| Weight | 0.89 oz (25.4 g) |
| Industry Compliance | |
| RoHS | EU Directive 2011/65/EU |
| CE | Yes |
| ATEX/IECEx | Compliant |
| Warranty | 1 year |
| Healthcare Sterilization Compliance | ISO 17665 – Moist Steam,
ISO 11135 – Ethylene Oxide |
